3H Hardware Concealed Tilt and Turn Window Hardware System YNXC07A Promotion
New short type concealed tilt and turn hardware system
This system is suitable for European standard 20-groove aluminum alloy tilt and turn windows;
The window is with the sash width ranges from 380mm to 500mm, and the sash height ranges from 620mm to 2200mm. (Note: the relative size of the top surface of the notch); the weight of the window sash is not more than 80KG.
What’s the advantages of this hardware system solution?
1. Can be adjustable
The bottom hinge is adjustable in three dimensions (left and right adjustable ±1mm, front and rear adjustable ±0.5mm, upward adjustable +3mm).Adjusting the eccentricity (+4/-2mm) of the rivet of the diagonal rod can reduce the gap between the frame and sash;
2.Suitable for different profiles
To prevent the sash from shaking, the diagonal rod can be adjusted according to different profiles;
3.Quick positioning and quick installation
All parts can be directly inserted into the groove for quick installation; the upper and bottom hinges are quickly installed and fixed directly with screws, without drilling to destroy the profile;
4.High air-tightness
There is no exposure on the inside and outside of the window, no need to cut the rubber strip, maintain the appearance of the whole window, improve the air-tightness of the door and window, and make the door and window both energy-saving and environmentally friendly.
Application Scenario
It’s suitable for aluminum alloy windows for residential, office buildings, shopping malls, hotels, hospitals and other civil buildings.
