Specification

Product Description

1. Selecting fixing screw based on the sash thickness.

2. Screw specification:M5 x Sash thickness +12mm.

3. Square shaft length:Sash thickness +46mm

4. The left and right version of handle are the same.

Performance index:

1. Operating standard:JG/T 124-2017 Construction Door and Window Hardware-Multi-point Handle

2. Repeatedly opening and closing for 25,000 times.

3. No load operation force is less than 40N,operation moment is less than 2N.m.

4. The handle can remain undamaged under 25N.m operation moment,the deviation from the handle

shank curve is less than 5 degree.

Scope of application

Casement doors,sliding doors of home and office buildings.
