Product Details

Factory Price Tilt and Turn Window System Hardware Accessories NXC06

Factory Price Tilt and Turn Window System Hardware Accessories NXC06 - Premium quality inswing window hardware system solution from Hehe Hardware.

Inquiry Now

Specification

Item No.

NXC06

Size

Minimum width of the frame is 435mm,minimum height is 620mm,maximum height is 1800mm

Application

 European standard 20 grooved window

Load Bearing

130KG

Material

304 stainless Steel,Zinc alloy

Surface Treatment

Powder coating

Color

handles' is customized,the other is natural

Components

Fork handle,European standard groove stay,Sealing cover strip...

Function

durable,reliable

Package

Box

Specification

Pizza cone oven-6

No.

Item Name

Remark

1

Slanting Connection Rod

Optional

2

Corner Device

/

3

Misoperation Device

/

4

Overturn Lock Rod

/

5

Upper Piovt Hinge

/

6

Bottom Piovt Hinge

/

7

Handle

The Fork Must not bumps

8

Lock Holder

/

9

Locking Plate

/

10

Supporting Block

/

11

Elevating Block

/

12

Stay

Optional

13

Aluminium Drawbar

La,Lb,Lc

14

Rubber Seal

Depending on the profile

15

Pull Rod Components

It's optional when window width is over 1100mm

Product Description

1. Achieve the inward opening and lower hanging multiple opening functions,thus,the window is flexible to be opened that it has the efficient heat-proof and sound-proof function,which can satisfy the different requirements and make the life colorful;

2. All the transmission part can be operated by the handle,which is easy and comfortable,and make the window, door and wall operate to the consistent interface;

3. Inserted hardware is adopted with the environmental plating process which can let the hardware has high corrosion resistance,and its anti-corrosion neutral salt spray test up to 10 hours;

4. About the appearance,there are 32 kinds of standard color for selecting to satisfy the customers’ different requirement;

5. The multiple level safety design with the standard components,compact structure and clamping structure that  can be operated very easy and comfortable;

6. This system is with the durable,reliable,tiny appearance and rich design that can lead the new technical design standard of hardware;

7. The system is suitable for European standard 20 groove.
