Fireproof Hinge FJX03 - Premium quality door & window hinge hardware from Hehe Hardware.
Item No. | FJX03 |
Size | / |
Application | casement window and door |
Load Bearing | 80KG/pair for window,200KG/pair for door |
Material | stainless steel |
Surface Treatment | powder coating |
Color | Optional |
Components | screws |
Function | durable,easy-installation,smooth-operation |
Specification
Product Description
1. Apply for 20 mm groove casement door and window.
2. Maximum load bearing for window is 80kg/pair,maximum load bearing for door is 200kg/pair.
3. Using excellent 304 stainless steel to stamp finishing.
4. Accord with the Class A fire-resistant requirement.
5. While installation,the screw should be installed into the profile inside.
Useage Notice
Project that need to be cleaned with corrosive solvent after installation
Skyscraper
Strong monsoon areas
Coastal areas
Carefully choose the hinge in circumstances above.Friction stay is suggested.
Note:Different hinge and profile lead to different location and size of the hole,please contact us.
