Specification

Product Description

1. Apply to the casement door which sash and frame are in a same plane,if not,and additional block should be installed on the border.

2. Maximum load bearing is 40KG/pair,the load bearing of hinge is relevant to hinge installation and profile.

3. The hinge is eccentric adjustable,the method is the same as installation instruction shown.

4. Divided into left and right version.
